DMA6500U 500W Class D 6 zone Amplifier with Fire Mute and zone attenuators
DSPPA Audio

DMA6 Series Digital Mixer Amplifier can be used in conjunction with the DMA20 Remote Paging Station, supporting 2-channel RJ-45 remote paging microphone. The amplifier has a screen for intuitive display, with such input sources as 4 MIC, 4 AUX, USB, FM, Bluetooth and TF. It also provides protection function when overload, clipping, short circuit and abnormal working temperature occur. It is an amplifier integrating multiple functions to meet users’ demand.


£0.00
£783.65
Earn0
reward points

In stock: 8

Sorry! We're out of stock


Oh No! This product is out of stock. Would you like to know when it's avaliable again?

Questions & Answers


John: What is the maximum number of microphone consoles I can have on one amplifier?A:

The Maximum is 6, the amplifier has 2 ports so they can be distributed over either port.

  • Specifications

    Model

    DMA6250U

    DMA6350U

    DMA6500U

    DMA6650U

    Power

    AC230V 50/ 60Hz

    Input Sensitivity

    MIC1

    10mV ±1mv (Balanced XLR Input)

    MIC2/MIC3/MIC4

    10mV ±1mv (Unbalanced Phoenix Jacks)

    AUX1

    350mV±50mv (Unbalanced RCA Input)

    AUX2

    350mV ±50mv (Unbalanced Phoenix Jacks)

    EMC

    350mV ±50mv (Unbalanced Phoenix Jacks)

    MIC Frequency Response

    120Hz~12kHz (±3dB)

    AUX Frequency Response

    80Hz~15kHz (±3dB)

    THD

    <1%

    Treble Adjustment Range

    10dB(±2)

    BASS Adjustment Range

    10dB(±2)

    Phantom Power

    +48V

    Rated Output Power

    250W

    350W

    500W

    650W

    Output Voltage of Port

    4-16Ω,70V,100V(fixed voltage output)

    Current

    2A

    3A

    4A

    Protection

    F3.15AL

    F6.3AL

    F8AL

    Machine Dimension(D×W×H)

    430×390×88mm

    Package Dimension:

    545×500×165mm

    Net Weight

    8.6KG

    9KG

    10.1KG

    11KG

    Gross Weight

    9.8KG

    10.2KG

    11.3KG

    12.2KG
