MA2250U Multimedia Mosque Amplifier 2x250W
DSPPA Audio
MA2250U is a 2-Channel multimedia mosque mixer amplifier with 2x250W RMS power. Separate channels output control of Echo/Bass/Treble/Volume and built-in 3 Mic and 1 AUX and USB/Bluetooth. Suitable for mosques, supermarkets, meeting rooms, training rooms and other places.
- 70V/100V & 4-16Ω speaker output
- Rated power: 2*250W
- Separate 2 channels output control of Volume/Echo/Bass/Treble
- Built-in 3 Mic and 1 AUX and USB/Bluetooth, 1 Chimes, 1 AUX output
- Combo for Mic1,XLR for Mic2 - Mic3, with phantom power 48V
- Individual volume control for Mic1-3 and Aux input
- Priority: Chime=MIC1-3>AUX/Bluetooth/USB
- Protection: Overload, Clipping, Short circuit and temperature protection
- With 19" rack mount handles
- Power supply: AC220V-230V/50/60Hz
£0.00
£537.01
- Specifications
Model
MA2250U
Rated Power
2×250W
Output Interface
Barrier Terminal Block
AUX Input Sensitivity
350MV
MIC Input Sensitivity
20kΩ/Balanced, 10kΩ/ unbalanced
SNR
≥75dB
Tone Adjustment
Bass:±10dBTreble:±10dB
Frequency Response
45Hz-20kHz（±1dB）
Distortion
<0.1%@1KHz
Power Supply
AC220-240V/50Hz
Protection
Load short circuit, DC output, power on/off, over temperature
Power Consumption
700W
Machine Size
（L×W×H）484×412×90mm
Package Size
（L×W×H）535×470×165mm
Net Weight
16.0kg
Gross Weight
16.8kg
- Manuals & Datasheets
